A 12 Volt Power Supply Circuit is an electrical circuit that provides a regulated 12V DC output from a variety of input sources. It is used in a wide range of applications, from powering small electronic devices to providing power for larger systems such as cars and boats. The circuit is designed to provide a stable voltage output, regardless of the input voltage or current. It is also designed to protect the connected devices from over-voltage, over-current, and short-circuit conditions.
